A4205 connector 4.2mm pitch

安装尺⼨ Mounting Measurement
⽴式 Straight Angle(V-Type)

A4205-H A4205-H
1.6
1.6
1.8 2.2
A
39 39
4.2 4.2

1.6 1.6
1.2 2.1 1.2 9.15 5
4.2
A4205-DHWV A4205-DHSV A4205-DHWV A4205-DHSV

卧式 Right Angle(R-Type) A4205 connector 4.2mm [.165] pitch

39.7 1.8

4.2
A4205-H A4205-WR
5.5
A4205-WR

端⼦ TERMINAL

A B
A-A B-B

1.7 1.6
A B 3.28 T11=3 T11=2.1 T12= T11=1.8
T11=3.3 T12= T12= 3 T12= 1.5

15.5
9.5
2.05

Part No. Section Area mm² Wire Range Insulation O.D Material Finish Qty/reel
A4205-TP 0.2 to 0.3 AWG #22 to #20 1.8 to 2.4mm Phosphor bronze Tin-plated 5,000pcs
A4205-T12P 0.3 to 0.5 AWG #24 to #22 2.4 to 2.7mm Phosphor bronze Tin-plated 5,000pcs

LIANHE ELECTRONICS CO.,LTD. 155
