A1251(51021) connector 1.25mm pitch

安装尺⼨ Mounting Measurement
⽴式 Straight Angle(V-Type)

5.2
A1251-H A1251-H
1.6 3
3.2 3.3
2.1
0.5 1.1
A
5.7 6
1.25
1.25
2.3 0.8
A1251-SV A1251-WV
A1251-WVB
A1251-WV A1251-WR
A1251-WVB A1251-WRB A1251-SV

卧式 Right Angle(R-Type)

5.2
3 1.6 A1251(51021) connector 1.25mm [.049] pitch

5.7 5.8 1.1

3.2 3.62
1.25
2.3 2.1
A1251-H A1251-WR 0.8
A1251-WRB
A1251-H A1251-WR
A1251-WRB
A1251-SR

端⼦ TERMINAL

A B A-A B-B

0.75 0.93 1.45 1.1

A B
1.6 1

3.3
0.8

1.45

1

Part No. Section Area mm² Wire Range Insulation O.D Material Finish Qty/reel
A1251-TP2 0.032 to 0.08 AWG #32 to #28 1.0mm(Max) Phosphor bronze Tin-plated 12,000pcs
