A25015 connector 2.5mm pitch

壳体 HOUSING
材料 Material: Nylon 66 UL94V-0 & Brass/Tin-plated

A2502-WV Poles Part No. DIM=A DIM=B DIM=C
2 A2502-WV02 2.50 7.50 1.00
C
2 3 A2502-WV03 5.00 10.00 1.20
4 A2502-WV04 7.50 12.50 2.00
5 A2502-WV05 10.00 15.00 2.00
7
6 A2502-WV06 12.50 17.50 8.60
7 A2502-WV07 15.00 20.00 11.10 A
3.4 -- -- -- -- -- --
20 A2502-WV20 47.50 52.50 43.60
2.5
A  0.64 2 A2502-SV02 2.50 7.50 1.00
B 5.8
3 A2502-SV03 5.00 10.00 1.20
4 A2502-SV04 7.50 12.50 2.00
5 A2502-SV05 10.00 15.00 2.00
6.5 6 A2502-SV06 12.50 17.50 8.60
-- -- -- -- --
20 A2502-SV20 47.50 52.50 43.60

材料 Material: LCP UL94V-0 & Brass/Tin-plated A25015 connector 2.5mm [.098] pitch

A2502-SV Poles Part No. DIM=A DIM=B DIM=C
2 A2502-SR02 2.50 7.50 1.00
B
C 3 A2502-SR03 5.00 10.00 1.20
2
4 A2502-SR04 7.50 12.50 2.00
5 A2502-SR05 10.00 15.00 2.00
7.9 6 A2502-SR06 12.50 17.50 8.60
7 A2502-SR07 15.00 20.00 11.10
-- -- -- -- --
6 2.2
20 A2502-SR20 47.50 52.50 43.60
2 A2502-DHWV02 2.50 7.40 1.00
3 A2502-DHWV03 5.00 9.90 1.20
4 A2502-DHWV04 7.50 12.40 2.00
5 A2502-DHWV05 10.00 14.90 2.00
2.5  0.64 6 A2502-DHWV06 12.50 17.40 8.65
A
B+2.5 -- -- -- -- --
16 A2502-DHWV16 37.50 42.40 33.65

材料 Material: LCP UL94V-0 & Brass/Tin-plated 材料 Material: Nylon 66 UL94V-0 & Brass/Tin-plated
A2502-SR A2502-DHWV
C
2
C 0.75 5.75
2
7.8
10

2.5  0.64 6.1 14.2
A
B
1.5
3.4

2.5  0.64
A 1.6 2
B 6.75
B+2.5

LIANHE ELECTRONICS CO.,LTD. 111
