A2541(杜邦2.54) connector 2.54mm pitch

安装尺⼨ Mounting Measurement
⽴式 Straight Angle(V-Type)

A2541-H A2541-HnX2 2.54

0.9 0.9
A
16.5 16.5 2.54

2.54
3 3
A2541-WV A2541-WVnX2
A2541-WV A2541-WVnX2 A2541-WR A2541-WRnX2

卧式 Right Angle(R-Type)

16.5 A2541(杜邦2.54) connector 2.54mm [.100] pitch
16.5
2.6
5.2
3
3
A2541-H A2541-WV
A2541-HnX2 A2541-WVnX2

端⼦ TERMINAL

A B
A-A B-B
1.6 2.7 1.6

2.55 1.65
A B

11.6
4.6
1.55

Part No. Section Area mm² Wire Range Insulation O.D Material Finish Qty/reel
A2541-TP2 0.13 to 0.33 AWG #26 to #22 1.2 to 1.6mm Phosphor bronze Tin-plated 10,000pcs
A2541-TP8 0.13 to 0.33 AWG #26 to #22 1.2 to 1.6mm Phosphor bronze Nickel-Gold 10,000pcs

LIANHE ELECTRONICS CO.,LTD. 113
