A2506(XA) connector 2.5mm pitch

安装尺⼨ Mounting Measurement
⽴式 Straight Angle(V-Type)

A2506-H
7
A2506-F
6.5
A
11.4
8.8 8

3.4 3.4

A2506-WV A2506-WV
A2506-WVG A2506-WVG
A2506-DWV A2506-DWV

+ 0.1 1.6 A2506(XA) connector 2.5mm [.098] pitch
 1.2 0 -
1.6

2.5 2.5

0.9 0.9

A2506-WV A2506-DWV

端⼦ TERMINAL

A B A-A B-B

1.8 2.9 1.9
0.8
A B 2.85 1.5

6.6
3.1

2.1 2.25

1.4

Part No. Section Area mm² Wire Range Insulation O.D Material Finish Qty/reel
A2506-TP2 0.08 to 0.5 AWG #28 to #20 0.8 to 1.9mm Phosphor bronze Tin-plated 8,000pcs

LIANHE ELECTRONICS CO.,LTD. 85
