A2004(杜邦2.0) connector 2.0mm pitch

安装尺⼨ Mounting Measurement
⽴式 Straight Angle(V-Type)

2
A2004-H A2004-H

0.7
0.8
A
9.2 9.2

2 2
2.8 2.8
A2004-WV A2004-WVnX2 A2004-WV A2004-WVnX2
A2004-WR A2004-WRnX2

卧式 Right Angle(R-Type)

9.2 A2004(杜邦2.0) connector 2.0mm [.079] pitch
9.2 2.16
4.1

2.8 2.8
A2004-H A2004-WV A2004-HnX2 A2004-WVnX2

端⼦ TERMINAL

A-A B-B
A B
0.35
1.4 1.65 1.4

A B 1.8 1.3

6.2
3.4

1.3 1.45

Part No. Section Area mm² Wire Range Insulation O.D Material Finish Qty/reel
A2004-TP2 0.05 to 0.13 AWG #30 to #26 1.4mm(MAX) Phosphor bronze Tin-plated 22,000pcs
A2004-TP8 0.05 to 0.13 AWG #30 to #26 1.4mm(MAX) Phosphor bronze Nickel-Gold 22,000pcs

LIANHE ELECTRONICS CO.,LTD. 41
