A2502(XHB) connector 2.5mm pitch

针座 WAFER
材料 Material: Nylon 66 UL94V-0 & Brass/Tin-plated

A2502-DHWV Poles Part No. DIM=A DIM=B DIM=C
2 A2502-DHWV02 2.50 7.40 1.00
C 0.75 5.75 3 A2502-DHWV03 5.00 9.90 1.20
2 4 A2502-DHWV04 7.50 12.40 2.00
5 A2502-DHWV05 10.00 14.90 2.00
6 A2502-DHWV06 12.50 17.40 8.65
A 7 A2502-DHWV07 15.00 19.90 11.15
14.2 -- -- -- -- --
16 A2502-DHWV16 37.50 42.40 33.65
1.5 2 A2502-DHWVB02 2.50 7.40 3.10
A2502(XHB) connector 2.5mm [.098] pitch
3 A2502-DHWVB03 5.00 9.90 3.10
3.4
4 A2502-DHWVB04 7.50 12.40 3.65
5 A2502-DHWVB05 10.00 14.90 6.15
2.5  0.64
A 1.6 2 6 A2502-DHWVB06 12.50 17.40 8.65
B 6.75
-- -- -- -- --
16 A2502-DHWVB16 37.50 42.40 33.65

材料 Material: Nylon 66 UL94V-0 & Brass/Tin-plated

A2502-DHWVB Poles Part No. DIM=A DIM=B DIM=C
2 A2502-DHWVC02 2.50 7.40 1.00
3 A2502-DHWVC03 5.00 9.90 1.20
C 0.75 5.75
4 A2502-DHWVC04 7.50 12.40 2.00
5 A2502-DHWVC05 10.00 14.90 2.00
6 A2502-DHWVC06 12.50 17.40 8.65
7 A2502-DHWVC07 15.00 19.90 11.15
14.2 -- -- -- -- --
16 A2502-DHWVC16 37.50 42.40 33.65
1.5 2 A2502-DHWVD02 2.50 7.40 3.10
3 A2502-DHWVD03 5.00 9.90 3.10
3.4
4 A2502-DHWVD04 7.50 12.40 3.65
2.5  0.64 5 A2502-DHWVD05 10.00 14.90 6.15
A 1.6 2
B 6.75 6 A2502-DHWVD06 12.50 17.40 8.65
-- -- -- -- --
16 A2502-DHWVD16 37.50 42.40 33.65

材料 Material: Nylon 66 UL94V-0 & Brass/Tin-plated 材料 Material: Nylon 66 UL94V-0 & Brass/Tin-plated
A2502-DHWVC A2502-DHWVD

C
2 0.75 5.75 C 0.75 5.75

14.2 14.2

3.4 3.4

2.5  0.64 2.5  0.64
1.8 A 2 1.8 A 2
B 6.75 B 6.75
