2.0mm Pitch, Housing, Double Row, 6 Circuits, Nylon 66 UL94V-0, White, Bag
C2006-H03X2
| Product category: C2006 SERIES | Picth:2.0mm |
| Temperature: -55℃~105℃ | Material: Nylon 66 |
| Current(Max)(A): 3 | Voltage – Maximum(VAC/DC): 100 |
| Wire rang(AWG): 22-26 | UL: E364711 |
| Keywords: 6 pin wire plug connector,6pin connector,cable connector 6 pin | |
| Product Type Features | Connector Product Type: Housing
Centerline (Pitch): 2.0 mm Connector System: Wire-to-Wire Product category: C2006-H03X2 |
| Specifications And Characteristics | Material – Resin and Flammability: Nylon 66 UL94V-0
Color: White |
| Configuration Features | Number of Positions: 6
Number of Rows: 2 |
| Electrical Characteristics | Voltage – Maximum(VAC/DC): 100
Current – Maximum per Contact(Max)(A): 3 |
| Usage Conditions | Operating Temperature Range: -55℃~105℃ |
| Industry Standards | UL: E364711 |
| Packaging Features | Packaging Method: Bag/Carton |
