| Product category: A5081 SERIES | Picth:6.35mm |
| Temperature: -25℃~105℃ | Material: Nylon 66, Brass Tin |
| Current(Max)(A): 12~10 | Voltage – Maximum(VAC/DC): 300 |
| Wire rang(AWG): 20-14 | UL: E364711 |
| Keywords:pa66 male connector,connector 10p,connector pcb | |
| Product Type Features | Connector Product Type: Wafer/Header
Centerline (Pitch): 6.35 mm Connector System: Wire-to-Board Product category: A6351-WRD05 |
| Specifications And Characteristics | Material – Resin and Flammability: Nylon 66 UL94V-2
Material-Metal: Brass Plating: Tin Plating Color: Natural/Beige |
| Configuration Features | Number of Positions: 5
Number of Rows: 1 |
| Electrical Characteristics | Voltage – Maximum(VAC/DC): 300
Current – Maximum per Contact(Max)(A): 12~10 |
| Usage Conditions | Operating Temperature Range: -25℃~105℃ |
| Industry Standards | UL: E364711 |
| Packaging Features | Packaging Method: Bag/Carton |
