| Product category: C3001&A3001 SERIES | Picth:3.0mm |
| Temperature: -25℃~105℃ | Material: Nylon 66, Brass Tin |
| Current(Max)(A): 8.5 | Voltage – Maximum(VAC/DC): 250 |
| Wire rang(AWG): 24-20 | UL: E364711 |
| Keywords: 8 pin electrical connector | |
3.0mm Pitch, Vertical Header, Double Row, 8 Circuits, Nylon 66 UL94V-0, Brass Tin, Black, Bag
A3001-DWV04X2
| Product Type Features | Product Name: 43045-0812 molex housing 8 pin electrical connector
Connector Product Type: Wafer/Header Centerline (Pitch): 3.0 mm Connector System: Wire-to-Board Product category: A3001-DWV04X2 |
| Specifications And Characteristics | Material – Resin and Flammability: Nylon 66 UL94V-0
Material-Metal: Brass Plating: Tin Plating Color: Black |
| Configuration Features | Number of Positions: 8
Number of Rows: 2 |
| Electrical Characteristics | Voltage – Maximum(VAC/DC): 250
Current – Maximum per Contact(Max)(A): 8.5 |
| Usage Conditions | Operating Temperature Range: -25~105 °C |
| Industry Standards | UL: E364711 |
| Packaging Features | Packaging Method: Bag/Carton
Packaging Quantity: 1000 |
